Parameter description (Local operation and FieldCare) Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus
154 Endress+Hauser
P01-xMx7xxxx-19-xx-xx-en-005
Fig. 44: BASIC SETUP function group for the "Level" measuring mode, depending on the setting for the LEVEL MODE
parameter, → ä 157, → Fig. 45 BASIC SETUP function group for the "Level" measuring mode and "Linear"
level mode
→ ä 165, → Fig. 47 BASIC SETUP function group for the "Level" measuring mode and "Pressure linearized"
level mode
→ ä 169, → Fig. 48 BASIC SETUP function group for the "Level" measuring mode and "Height linearized"
level mode.
FULL HEIGHT (006)
Entry
Enter the height value for the upper calibration point (container full). The unit is selected
via the HEIGHT UNIT parameter (→ ä 152).
→ See also FULL CALIB.
Prerequisite:
• CALIBRATION MODE = Dry
Factory setting:
Upper range limit (URL) is converted to a unit of height
DAMPING VALUE (247)
Entry
Enter damping time (time constant τ).
The damping affects the speed at which all subsequent elements, such as the local
operation, measured value and OUT value of the Analog Input Block react to a change in
the pressure.
Input range:
0.0 to 999.0 s
Factory setting:
2.0 s or as per order specifications
Table 9: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL SELECTION "Level easy height"
Parameter name Description
*
*
*
Linear
Pressure Linearized
Height Linearized
Parameters marked with an asterisk "*"
are not always displayed.Thedisplay
depends on the settings of other parameters,
see the following Table.
FlowPressure
Level
PRESS. ENG. UNIT
CUSTOMER UNIT P
CUST. UNIT FACT. P
LEVEL MODE
MEASURING MODE
MEASURED VALUE
QUICK SETUP
BASICSETUP
DISPLAYSETTINGS
POSITION ADJUSTMENT
OPERATING MENU
EXTENDED SETUP
