3.1 Product design
3.1.1 Micropilot FMR10
1
8
9
2
3
4 5
6
7
A0028415
 1 Design of the Micropilot FMR10 (26 GHz)
1 Sensor housing
2 Seal
3 Process connection rear side
4 Cable gland
5 Pipe adapter
6 O-ring
7 Counter nut
8 Design ring
9 Process connection front side
