40
Accessible Without Code Entry:
Measured value displays
Error list
Info list
Logbook
Calibration data history
Air Set Info (toroidal)
Accessible With Operator Code:
Short-cut to relays
Calibration parameters
Temperature measurement type (ATC, MTC)
Internal data (instrument number, SW no., module info.)
Language, date, time, tag no., contrast, operator code
Accessible With Advanced Code:
All menus and functions
Caution!
If the codes are lost, unlocking is possible with the default code 7156. A new
code can then be set in the Commissioning / System set-up menu.
All calibration functions are accessible at the operator (maintenance) and
advanced (specialist) levels.
6.7 The Short-Cut to Relays Menu
This menu gives you direct access to the main functions without having to go through the
entire configuration menu. The short-cut menu includes the following functions:
Hold On / Off
Manual/Automatic contact operation
Limit settings
® Short-cut to relays
Selection
Hold on / hold off
Automatic on
Automatic off
Start cleaning (if Chemoclean on)
Automatic / manual operation
When manual operation is
selected:
Contact 1 off / on
Contact 2 off / on
1)
Current state is indicated
Entry of limit 1
Entry of limit 2
1)
Function
Hold
Clean function
Limit contacter operating mode
Limit contacter setpoints
Short-Cut to Relays Menu
Factory setting
Hold off
Last setting
Manual operation
Contact 1 off
Contact 2 off
5% full scale
95% full scale
1)
If the second contact is configured as a limit contacter.
