Main display: Conductivity value measured in mS/cm or µS/cm
(large characters for reading from a distance)
Suppl. info: Measuring range (measuring range switching only)
Main display: Conductivity value measured in mS/cm or µS/cm
Suppl. info: Measuring range (remote meas. range switching only)
Type of temperature compensation
Substance measured
Current compensation temperature
Main display: Conductivity value measured in mS/cm or µS/cm
Suppl. info: Same as 2nd measured value display plus
contact states (limit contacter only)
Main display: Difference in conductivity measured ( DCD)
in mS/cm or µS/cm
Suppl. info: Measuring range (measuring range switching only)
Main display: Difference in conductivity measured ( DCD)
in mS/cm or µS/cm
Suppl. info: Measuring range (measuring range switching only)
Type of temperature compensation
Substance measured
Current compensation temperature
Main display: Difference in conductivity measured ( DCD)
in mS/cm or µS/cm
Suppl info: Same as 2nd measured value display plus
contact states (limit contacter only)
Main display: Conductivity value measured, channel 1 (CD1)
in mS/cm or µS/cm
Suppl. info: Same as third measured value display
Main display: Conductivity value measured, channel 2 (CD2)
in mS/cm or µS/cm
Suppl. info: Same as third measured value display
Main display: Concentration value measured in % (large characters)
Suppl. info: Measuring range (measuring range switching only)
Substance name
Main display: Concentration value measured in %
Suppl. info: Same as first measured value display plus
type of temperature compensation,
current compensation temperature
Main display: Concentration value measured in %
Suppl. info: Same as 2nd measured value display plus
contact states (limit contacter only)
Main display: Concentration value measured in %
Suppl. info: Same as first measured value display plus
conductivity value measured
Main display: Concentration value measured in %
Suppl. info: Same as third measured value display plus
conductivity value measured
One-
circuit
Difference
One-
circuit
6.5 Measured Value Displays
The  and ¯ keys can be used to select different measured value display formats. These
formats differ in the size of the display characters and the amount of supplementary
information displayed.
Note!
Contact status is only displayed if one or two contacts are configured as limit
contacts.
Conductivity Measurement
1st meas.
value
display
2nd
meas.
value
display
3rd meas.
value
display
1st meas.
value
display
2nd
meas.
value
display
3rd meas.
value
display
4th meas.
value
display
5th meas.
value
display
1st meas.
value
display
2nd
meas.
value
display
3rd meas.
value
display
4th meas.
value
display
5th meas.
value
display
Concentration Measurement
