87
Output Specifications Output signal Digital communication signal, PROFIBUS PA
PA function Slave
Response: Slave Approx. 20 ms
PLC Approx. 600 ms for approx. 30 devices
Failure signal PROFIBUS PA: signal status bit is set, last valid
measured value is held
Integration time 0 to 99 s, default 0 s
Communication resistance None, separate PROFIBUS PA terminating resistor
Physical layer IEC 1158-2
Integrated overvoltage protection 25 VAC / 250 A
Display and User Remote control Via PROFIBUS PA with operating program Commuwin II
Interface Communication interface PROFIBUS PA
Power Supply Supply voltage 9 to 32 VDC
Current consumption 10 mA ± 1 mA
Inrush current Corresponds to table 4, IEC 1158-2
13.2 Profibus PA
(Subject to change without prior notice)
