13.1.4 General Technical Data
Limit and Alarm Function Limit Contacter
Functions Function type MIN or MAX
Setpoint settings (in absolute values) 0 to 100% of DR
Hysteresis for switched contacts (in absolute values) 1 to 10% of DR
Pickup / dropout delay 0 to 7200 s
Alarm threshold 0.5 to 100% of DR
Alarm delay 0 to 6000 s
Electrical Data and Power supply, AC 24/100/115/200/230 V +10 / 15%
Connections Frequency 47 to 64 Hz
Power supply, DC 24 V, +20 / 15%
Power consumption Max. 10 VA
Contact outputs (optional) Potential-free changeover contacts (Ex
version: optocouplers), configurable
as NO or NC contacts
Switching current Max. 3 A
Switching voltage Max. 250 VAC / 125 VDC
Switching power Max. 750 VA
Signal outputs 2 x 0/4 to 20 mA, isolated from other
circuits but not from each other
Isolation voltage 276 V
rms
Current output
Current range 0/4 to 20 mA
Measurement deviation 0.2% of upper current value
Load Max. 600W
Terminals, maximum cable cross section 2.5 mm
2
General Technical Data Measured value display Illuminated LC display with 128 x 64
dot matrix
Electromagnetic compatibility (EMC)
Emitted interference acc. to EN 50081-1, 01.92
Interference resistance acc. to EN 50082-2, 03.93
Nominal operating conditions
Ambient temperature 14 to 131°F (10 to +55°C)
Relative humidity 10 to 95% non-condensing
Limit operating conditions
Ambient temperature 4 to 140°F (20 to +60°C)
Storage and transport temperature 13 to +185°F (25 to +85°C)
Physical Data Dimensions (HxWxD) 9.72 x 6.57 x 4.37 (247x167x111 mm)
Weight Max. 13.23 lbs (6 kg)
Protection type NEMA 4X, IP 65
Materials
Housing Diecast AISi 12 (Mg content < 0.05%),
plastic-coated
Front Polyester, UV-resistant
(Subject to change without prior notice)
