5 First Start-up
5.1 Measures Before the First Power-up
Familiarize yourself with the operation of the transmitter before switching it on for the first
time!
Caution!
Make sure all connections have been established correctly before power-up!
Make sure the measuring cell is located in the medium or in a calibration solution.
If it is not, implausible readings are to be expected.
Warning!
Before power-up, make sure that there is no risk of damage to the system that the
instrument is part of; for example, due to valves, pumps etc. that might operate
in an uncontrolled manner.
5.2 The Set-up Guide Menu
When it is powered up for the first time, the instrument is in the Set-up guide menu. All the
setting data needed for operation is checked here. This automatically guarantees that all
the selections required for operation are made.
First, the instrument prompts for the language to be used for text displays. The selections
available are shown. Select the English line it appears in reverse video and confirm
your choice by pressing the E (Enter) key. Your selection is stored, and the next
prompt is displayed.
Proceed in the same manner for all other prompts.
You can abort the set-up guide procedure by pressing the CAL, DIAG, MEAS or
PARAM key.
The set-up guide menu will come up every time the instrument is powered up until the
procedure is completed all the way, acknowledging the last field with end.
Thereafter, the start-up routine can be accessed via the menu structure following entry
of the advanced (specialist) code.
