75
11.5 Service
11.5.1 Simulation
Function Selection
Setting of present current value for current 0.00 to 22.00 mA
output 1
Setting of present current value for current 0.00 to 22.00 mA
output 2
Setting of current relay statuses The contacts are selected with the
(the number of contacts displayed depends and ¯ keys. The selected contact is
on the modules installed and the opened/closed with the ® key.
configuration)
Measured value simulation Can be set to any value within
main measured value configured measuring range. Current
outputs and relay states change
according to configuration.
Measured value simulation, temperature 31 to +482°F (35.0 to +250.0°C)
Current outputs and relay states change
according to configuration.
® Service
Operator Level
Advanced Level
® Simulation + Chapter 11.5.1
® Internal data + Chapter 11.5.2
® Factory settings + Chapter 11.5.3
® Instrument check + Chapter 11.5.4
® Special functions + Chapter 11.5.5
Note!
The displayed current output value or relay state immediately appears in the
Simulation menu. If the value in the window is changed, the current output or
relay state immediately changes accordingly. The simulation function is
deactivated by leaving the window.
11.5.2 Internal Data
Function Selection
Display of the device number No selection
Display of the software version No selection
Display of the software version of FCL1 No selection
module (conductivity signal processor),
channel 1
Display of software version, channel 2 No selection
Display of the hardware configuration in
several consecutive windows; assembly
(module), installation date, slot information No selection
Order code Alphanumeric entry, may include
numbers from 0 to 9 and characters
from a to Z
Reset counter 0 to 255, display only
