Refer to Figure 1–9, Figure 1–10 or Figure 1–11 for label placement.
Failure to follow all directions may result in damage or
malfunction of the analyzer.
Protective Earth Ground symbol indicates the connection
point of the ground wire from the main power source.
Earth Ground symbol indicates secondary grounding points.
INVISIBLE LASER RADIATION -
Avoid exposure to beam. Class 3b
Radiation Product. Refer servicing to the
manufacturer-qualified personnel.
INVISIBLE LASER RADIATION -
Avoid exposure to beam. Class 3b
Radiation Product. Refer servicing to the
manufacturer-qualified personnel.
Maximum Cell Pressure label stating
maximum allowable pressure in
measurement cell.
Maximum Sample Pressure label stating
maximum allowable sample inlet
pressure.
SAMPLE CELL
PRESSURE SET @
689.5 MBAR MAX
(10 PSIG MAX)
SAMPLE IN
689.5 MBAR MAX
(10 PSIG MAX)
