SS2100r H
2
S Analyzer
1–16 4900002189 rev. D 3-7-18
TB1
TB2
P/N REV
ELECTRIC SHOCK
WARNING LABEL
TERMINAL
LABEL
FUSE
LABEL
ENERGIZED FUSE
WARNING LABEL
ENERGIZED FUSE
WARNING LABEL
PROTECTIVE EARTH
GROUND LABEL
ELECTRIC SHOCK
WARNING LABEL
GENERAL
WARNING LABEL
Figure 1–11 Label placement on
the analyzer electronics assembly
