SS2100r H
2
S Analyzer
1–12 4900002189 rev. D 3-7-18
Special Safety Symbols and Labels
In addition to the icons used in this manual for instruction, special safety
symbols and labeling are used on the equipment to alert the user to potential
hazards and important information associated with the analyzer. Every symbol
and label has significant meaning that should be heeded. Some of these
symbols are provided for instructional purposes only and are not labeled on the
system.
Equipment Labels
Table 1–1 Fuse specifications
DWG Ref. Voltage Description Rating
Figure 1–8,
F1, F2
120 VAC Miniature Fuse, 5 x 20 mm, Time Delay 250VAC/1.0 A
Figure 1–8, F3 24 VDC Miniature Fuse, 5 x 20 mm, Time Delay 250 VAC/1.6 A
Figure 1–5
F4, F5
230 VAC Miniature Fuse, 5 x 20 mm 250VAC/5.0 A
Fuse Rating label stating maximum
voltage and current specifications for
the fuse closest to label.
Fuse location and maximum voltage.
Analyzer Rating label stating maximum
input voltage and power.
Do Not Remove label stating that
removal of the seal and/or disassembly
of pieces traversed by label voids the
warranty.
Electric Shock Hazard symbol located near exposed wires
and/or surfaces that pose a potential shock hazard.
WARNING - DO NOT REMOVE OR
REPLACE FUSE WHEN ENERGIZED
FUSE: 5X20MM, T, L, 250VAC, 1AMP
VOLTS:
POWER:
FUSE TYPE:
230V~50HZ, 1P
120 WATTS
5X20MM, T, L,
250VAC, 2.5AMP
WARNING
DO NOT REMOVE!
REMOVAL OF THIS SEAL VOIDS WARRANTY
