Endress+Hauser SpectraSensors SS2100r - Figure 1-9 Label Placement on Front and Rear of Analyzer Enclosure

SS2100r H
2
S Analyzer
1–14 4900002189 rev. D 3-7-18
CLASS I LASER
PRODUCT LABEL
CE MARK
LABEL
ANALYZER
RATING LABEL
GENERAL
WARNING LABEL
MANUFACTURER
LABEL
SYSTEM
SERIAL TAG
FRONT
REAR
SAMPLE CELL
PRESSURE SET @
689.5 MBAR MAX
(10 PSIG MAX)
MAXIMUM CELL
PRESSURE LABEL
MAXIMUM SAMPLE
PRESSURE LABEL
IN
Figure 1–9 Label placement on front and rear of
analyzer enclosure
