Spare Parts
Below is a list of replaceable spare parts that can be ordered for the SS2100r
analyzer. To order, contact “Customer Service” on page B-11.
Table A–2 Replacement parts for SS2100r
Part
Number
Description
2 Year
Qty.
Electronics
2900000380 PCBA, Assembly, Daughter Board, H
2
S, RoHS -
2900000450 4-20mA Board, Dual Adjust, Low Noise, RoHS -
2900000430
PCBA, Auxiliary Interface Board, Hybrid, RoHS (L-Board)
1
-
4000002038 Watlow Temperature Controller, Ez-Zone RM -
8000002013 Power Supply, Traco -
4500002002
Relay, w/ Socket, C1D2, 6A, DC12V, SPDT (TB1)
-
2800002063 861 Solid State Relay with Internal Heater -
2460100002
Display, LCD, 20 x 4, Backlit, 5V, Serial
1
1. Contact SpectraSensors’ service department before attempting replacement. Replacing this component
without technical support could cause damage to other components. Refer to “Service Contact” on
page B-11.
-
4500002012 Fuse, Miniature, 5 x 20 mm, 1 Amp (110 VAC)/1 Amp (240 VAC) 2
4500002016 Fuse, Miniature, 5 x 20 mm, 2.5 Amp (110 VAC)/1 Amp (240 VAC) 1
4500002018 Fuse, Miniature, 5 x 20 mm, 5 Amp (230 VAC) 2
Sample Conditioning System
6134100674 Flowmeter, 0-6 SLPM, Glass, Valve -
6100002283 Pressure Gauge, 30 PSIG, Panel Mount, 1/8 FNPT (SS) -
6100002284 Pressure Regulator, 25 PSIG, Panel Mount, 1/4 FNPT (SS) -
EX6100000001 Valve, Solenoid, ATEX, 3-Way, 230V -
Kits/Cables
1100002207 Kit, Assembly, Temperature Control Board, Hytek, 28M Retrofit -
0219900006
Kit, Spares (O-rings, Screws), Viton, 2-Pass Cell
1
1
0219900011 Kit, Fuse, AC/DC 1
0190217106 External Serial Output Cable -
6000002105 Cable, Internal, Temperature/Pressure, 19” Rack -
6000002103 Cable, Internal, Optical Head, 19” Rack -
6000002107 Cable, Assembly, Signal, Optical Head, 19” Rack -
8000002470 Assembly, Internal, RS-232 Serial and 4-20 mA -
