Endress+Hauser SpectraSensors SS2100r - Figure 3-1 Predicted Scrubber Lifetime Based on Average H 2 S Load; Figure 3-2 Scrubber and Scrubber Efficiency Indicator

SS2100r H
2
S Analyzer
3–2 4900002189 rev. D 3-7-18
Figure 3–1 Predicted scrubber lifetime based on
average H
2
S load
SCRUBBER
CLAMP
SCRUBBER
SWAGELOK
NUTS
FLOW
Figure 3–2 Scrubber and scrubber efficiency
indicator
