4.1.1 Description menu configuration Display
SCAL method
The input and display values are programmed manually. This method can be used when the value of the signal supplied by the
transducer at each points of the process is known.
tEACH method
The input values are introduced directly from the signal present in the input connector when each point is programmed. The
display values are programmed manually.
This method can be used when it is possible to bring the process to the conditions of each one of the points to be programmed.
Programming scale points
Input points
- 19999
to
99999
Display points
- 19999
to
19999
Display decimal point
0 0.0 0.00 0.000 0.0000
Accessible from the SCAL or tEACH menu, following the first display point. Once acceded to it , it will start to blink in its present
position and through the key will be able to shift to another position.
Moreover it will also affect, as well as the display points, the setpoints value and the value of the analog output scale, in case the
corresponding option has been installed.
