5.2.2 Table of programmable functions
• Nº: Number to select the function by software.
• Function: Function name.
• Description: Description and characteristics of the function.
• Activation by:
Falling edge: the function is activated applying a falling edge to the corresponding pin with respect to common.
Low level: the function will remain activated as long as the corresponding pin is held at a low level.
* It’s mandatory programming the 3 logical inputs with function 16
TABLE DE FONCTIONS LOGIQUES
Nº Fonction Description Activation by
0 Deactivated None None
1 Deactivated None None
2 Deactivated None None
3 PEAK Displays the peak value. (MAX.) Low level
4 VALLEY Displays the valley value. (MIN) Low level
5 RESET
PEAK/VALLEY
Perform a reset of the peak or the valley, depending on which is being
displayed.
Falling edge
6 HOLD Freeze the display while all the outputs remain active Low level
7 PRINT Sends the display value to the printer Falling edge
8 Deactivated None None
9 Deactivated None None
10 ASCII Sends the last four digits to a ASCII interface Falling edge
11 BRIGHTNESS Change the display brightness from Hi to Low Low level
12 SETPOINT VALUE Displays the selected setpoint value (see diagram next page) Low level
13 False Setpoints Simulates that the instrument has a four setpoints option installed Low level
14 PRINT MAX Sends the MAX value to the printer Falling edge
15 PRINT MIN Sends the MIN value to the printer Falling edge
16 Remote keypad The three logic inputs act as a remote keypad * Falling edge
