7.1.7 Direct access to the setpoints value programming
If any of the options corresponding to the setpoints has been installed, it is possible to accede directly to the setpoints value
without need to go through the programming menu just by pressing the key in PROG mode, as showed in diagram below,
supposing that the card installed are 4 Relays SPST, 4 Outputs NPN or 4 Outputs PNP, if it is the 2 Relays SPDT card only Set1 y
Set2 would appear.
Remember that the decimal point position comes determined by what
has been programmed in the SCAL menu.
