14
Dimensional sketches
Maxi 31/40 – series
A: Height
B: Length
C: Width incl. line wheel
D: Width excl. line wheel
200 mm
370 mm
230 mm
160 mm
Maxi 32 – series
A: Height above deck
B: Length above deck
C: Width above deck, incl. line wheel
D: Width excl. line wheel
E: Height below deck
200 mm
255 mm
230 mm
160 mm
150 mm
