Replacing the line wheels
If the line guide spring (see the drawing on the following page, pos. 46) is too
slack, or if there is not sufficient space for the rope below the windlass, the rope
can, in time, slip on the gypsy, resulting in the gypsy becoming worn. If you need
to replace gypsies (pos. 14 and 15), follow the procedure described below:
Loosen and remove the screws and washers (16 and 17).
Remove the outer gypsy and cover (13 and 15).
Loosen and remove the screws (25) and the rope guard/rope guide set
(29 and 4).
NB If necessary, remove the auto stop switch (6) by loosening the nuts (61)
and pull the switch out to access the screws.
Remove and replace the inner line wheel.
Reverse the process to assemble and fit the new outer gypsy.
NB Put contact adhesive (e.g. Locktite) on the screw (17) before tightening it.
NB Recommened torque for bolts, 20Nm
