Technical
specifications
ENGBO MAXI 31, 32, 33, 34, 38 and 40
Motor output, nom.
-12V DC / 1000 W
-24V DC / 1500 W
Rope
(for rope windlasses)
Woven lead rope: dia. 16 mm. Breaking strain: 4000 kg
Woven lead rope: dia. 14 mm. Breaking strain: 3300 kg
Length:
50 m, weight, 21.7 kg
75 m, weight, 32.0 kg
100 m, weight, 43.0 kg
Chain (for chain
windlasses)
6.5 mm, short link Norwegian std. Breaking strain: 2300 kg
8 mm DIN 766 std. Breaking strain: 4000 kg
Pulling power
(Electronically governed)
Rope windlasses:
1000 W, up to approx. 500 kg
1500 W, up to approx. 650 kg
Chain windlasses: up to approx. 850 kg
Pulling speed
20–25 m/min with a load of approx. 40 kg
Power consumption
80–200 A during normal operation
Recommended fuses
1000 W/12V and 1500 W/24V, 250 A
Recommended min.
battery capacity
12V/100Ah
24V/75 Ah
Weight: windlass with
motor and cables
Approx. 20 kg
Weight: electronic unit
2.3 kg
Auto stop function
Yes (NB Only for rope windlasses)
Recommended anchor/
weight
Engbo / Bruce / Spade /10–30 kg
Recommended boat size
Over 25-foot
Fitting
See the separate descriptions for the individual models
Standard equipment
Windlass incl. cables for electronic module, electronic
module, switch panel and main power switch
Supplementary
equipment
Anchor (Multiple types)
Anchor bracket (Multiple types)
Battery cable
Lead rope or chain
Fuse w/holder
Hull conduit for rope or chain
Wireless remote control
