93
WSG-1068 ENGINE
1. Disconnect the battery ground cable (14301).
2. Remove the engine front cover (6019) and crankshaft
sprockets (6306); refer to Engine Front Cover in this
section.
3. Remove the oil pan (6675); refer to Oil Pan in this
section.
4. Remove the oil pump (6600).
Remove the bolts.
Remove the oil pump
1. Clean and inspect the mating surfaces.
2. Position the oil pump and loosely install the bolts.
Tighten the bolts in the sequence shown.
3. Install the oil pan; refer to Oil Pan in this section.
4. Install the timing chain (6268); refer to Timing Drive
Components in this section.
5. Connect the battery ground cable.
