101
WSG-1068 ENGINE
6. At the oil cooler water inlet, disconnect and set aside
the lower radiator hose (8286).
7. Disconnect the engine harness.
8. Remove exhaust pipe nuts.
9. Drain engine oil and remove the oil bypass filter
(6714).
10. Remove the starter motor (11002); refer to Section
07.
To Next Page
