115
WSG-1068 ENGINE
23. Remove the oil level dipstick, the bolt and the oil
level indicator tube (6754).
24. Install the Lifting Handles on both ends of the cylinder
head.
25.
CAUTION: These bolts must be replaced
with new bolts. They are tighten-to-yield
designed and cannot be reused.
Remove the bolts, cylinder head, and head gasket.
Discard the head gasket (6051), cylinder head
bolts and clean the engine block surface.
LH is shown; RH is similar.
To Next Page
