150
WSG-1068 ENGINE
65.
CAUTION: Mating parts must make contact
to each other within 4 minutes and connecting
bolts must be torqued within 15 minutes after
applying sealant. Failure to follow this procedure
can cause future oil leakage.
Use silicone gasket and sealant F6AZ-19562-AA
or equivalent meeting Ford specification
WSEM4G323-A6.
NOTE: Sealant must be removed and area cleaned with
solvent if above instructions are not followed.
Use metal surface cleaner F4AZ-19A536-RA or
equivalent meeting Ford specification WSEM5B292-
A.
Apply silicone to the Woodruff key slot on the
crankshaft pulley (6312).
Use Silicone Gasket and Sealant F6AZ-19562-A
or equivalent meeting Ford specification
WSEM4G323-A6.
66. Use the Crankshaft Damper Replacer to install the
crankshaft pulley.
67. Tighten the crankshaft pulley bolt (6A340) in four
stages.
Stage 1: Tighten to 90 Nm (66 lb/ft).
Stage 2: Loosen 360 degrees.
Stage 3: Tighten to 47-53 Nm (35-39 lb/ft).
Stage 4: Tighten an additional 85-90 degrees.
