200
WSG-1068 COOLING SYSTEM
Cylinder Head Temperature (CHT) Sensor
- Replacement
1. Remove the upper and lower intake manifold
together. For additional information, refer to
Section 01.
2. Remove the cylinder head temperature (CHT)
sensor.
1. Disconnect the electrical connector.
2. Remove the CHT sensor.
3. To install, reverse the removal procedure.
CAUTION: Do not over torque. May damage
sensor.
Fan Drive Belt - Removal and Installation
1. Rotate the drive belt tensioner counterclockwise
and remove the drive belt.
2. NOTE: Refer to 05-9 for correct drive belt
routing. To install, reverse the removal
procedure.
