43
WSG-1068 ENGINE
14. Separate the upper and lower intake manifolds (9424).
Remove the ten bolts.
Discard the intake manifold gasket.
15. Clean all mating surfaces.
Intake Manifold – Variable Resonance
Induction System (VRIS) - Installation
1. Position the lower intake manifold gasket (9461) and
the upper intake manifold on the intake manifold and
loosely install the ten bolts.
