45

WSG-1068 ENGINE
5. Install the upper intake manifold.
 Position the upper intake manifold gaskets and
the intake manifold, and loosely install the bolts.
6. Install the thermostat, gasket and the thermostat
housing and loosly install the bolts.
7. NOTE: Be sure to tighten the bolts in two stages.
Tighten the bolts in the sequence shown.
 Stage 1: Tighten to 2 Nm (18 lb/in).
 Stage 2: Tighten to 20-30 Nm (15-22 lb/ft).
