47
WSG-1068 ENGINE
13. Connect the engine vacuum hoses.
Vacuum source.
14. Connect the engine water outlet hose and position
the hose clamp.
15. Install the air cleaner outlet tube (9B659).
16. Fill the cooling system; refer to Section 05.
17. Install the engine cover.
18. Connect the battery ground cable.
Valve Cover – Left - Removal
1. NOTE: The bolts are a part of the valve cover (6582)
and are not to be removed.
Fully loosen the valve cover.
Remove the two nuts and the sixteen bolts, and
remove the valve cover and the valve cover gasket
(6584).
