63
WSG-1068 ENGINE
4. Remove the balance shaft.
5.
CAUTION: Unless otherwise instructed,
at no time when the timing chains (6268) are
removed and the cylinder heads (6049) are
installed may the crankshaft or camshaft (6250)
be rotated. Severe piston (6108) and valve
damage could occur.
Use the Crankshaft Holding Tool to position the
crankshaft as shown.
To Next Page
