79
WSG-1068 ENGINE
4. Use the Valve Spring Compressor to compress the
valve springs and install the camshaft roller
followers.
5. Lubricate the balance shaft journals with engine oil.
Use Super Premium SAE 5W30 Motor Oil D9AZ-
19579-A or equivalent meeting Ford specification
WSS-M2C153-G.
6. Using the index mark on the balance shaft, mark the
corresponding teeth on the gear with chalk.
7. Position the balance shaft on the journals.
8. Align the balance shaft timing marks as shown.
Align the chalk mark on the balance shaft with the
camshaft timing mark as shown.
