Enomatic eno one - Technical Characteristics

eno one 2/r - user manual
REV.05
10
9. TECHNICAL CHARACTERISTICS
Kg
12 Kg
26.46 lb
6 °C ÷ 18 °C
276 mm
10.88 in 13.83 in
351 mm
L= 275 ÷ 330 mm
L= 10.83 ÷ 13 in
598 mm
23.55 in
43 °F ÷ 64 °F
ø < 110 mm
ø < 4.33 in
ø ≤ 90mm
ø ≤ 3.54 in
L= 275 ÷ 330 mm
L= 10.83 ÷ 13 in
CHARACTERISTICS AND COMPONENTS
The Dispenser in the sale conguration allows the insertion of bottles with a maxi-
mum diameter and a height range indicated in the image below.
The right bottle location (when facing the Dispenser), allows the insertion of bottles
with a diameter less than the left side due to the size of the thermoelectric refrigera-
tion system (O).
