Installing Optional Mini-GBICs
3-4 Hardware Installation
Figure 3-3 Mini-GBIC with MT-RJ Connector
Figure 3-4 Mini-GBIC with LC Connector
1 Mini-GBIC (MGBIC-MT01) 4 Port slot
2 Mini-GBIC, top side 5 Protective dust cover
3 7-pin edge connector (insertion side) 6 Release tab
1 Mini-GBIC
(MGBIC-LC01, -LC03, or -LC09) 4 Port slot
2 Mini-GBIC
, top side 5 Protective dust cover
3 7-pin edge connector (insertion side) 6 Release tab
