Using LANVIEW
SecureStack B2 Installation Guide 4-3
Figure 4-23 B2H124-48P LANVIEW LEDs
Table 4‐4describestheLEDindicationsandprovidesrecommendedactionsas
appropriate.
1 CPU LED 6 Link/Activity LED for 10/100 Mbps, port 1
2 STACK DOWN LED 7 Link/Activity LEDs for 10/100 Mbps,
3 STACK UP LED RJ45 ports 1 through 48
4 RPS LED for redundant power-source status 8 Link/Activity LEDs for 1-Gbps Mini-GBIC
5 Manager LED ports 49 through 52
1
1. Unlike the B2G124-48P, all 52 ports can be active at the same time.
Note: The terms flashing, blinking, and solid used in Tab l e 4- 4 indicate the following:
Flashing: LED is flashing randomly.
Blinking: LED is flashing at a steady rate (approximately 50% on, 50% off).
Solid: LED is on steady and not pulsing.
Console
1
2
49
CPU
UP
RPS
MGR
DOWN
50
51
52
47
48
B2H124-48P
1234567 8910111213141516
15
16
17
18
31
32
33
34
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
CPU
UP
RPS
MGR
DOWN
Á
Â
Ã
Ä
À
Ç
Æ
Å
