Gigabit Ethernet Specifications
A-4 Specifications
Gigabit Ethernet Specifications
ThefollowingspecificationsfortheMini‐GBICs showninTable A‐3throughTable A‐10
meetorexceedtheIEEE802.3z‐1998standard.
MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)
MGBIC-LC03 Specifications (1000BASE-SX)
Table A-3 MGBIC-LC01/MGBIC-MT01 Optical Specifications
Item 62.5 µm MMF 50 µm MMF
Transmit Power (minimum) -9.5 dBm -9.5 dBm
Receive Sensitivity -17 dBm -17 dBm
Link Power Budget 7.5 dBm 7.5 dBm
Table A-4 MGBIC-LC01/MGBIC-MT01 Operating Range
Item
Modal Bandwidth @
850 nm
Range
62.5 µm MMF 160 MHz/km 2-220 Meters
62.5 µm MMF 200 MHz/km 2-275 Meters
50 µm MMF 400 MHz/km 2-500 Meters
50 µm MMF 500 MHz/km 2-550 Meters
Table A-5 MGBIC-LC03 Optical Specifications
Item 62.5/125 µm MMF 50/125 µm MMF
Transmit Power (minimum) -9.5 dBm -9.5 dBm
Transmit Power (maximum) -3 dBm -3 dBm
Receive Sensitivity -20 dBm -20 dBm
Link Power Budget
1
(Multimode Only)
1. The maximum drive distance (up to 2 km) depends on the quality of the installed multimode
fiber-optic cable segment. Use the Link Power Budget to calculate the maximum cable length of the
attached segment. The Link Power Budget must not exceed those specified in this table. The
MGBIC-LC03 input power must not exceed -3 dBm. Otherwise, saturation could occur.
10.5 dB 10.5 dB
