Overview
1-2 Introduction
C2G124-24 and C2G124-48
TheC2G124‐24(Figure 1‐1)andC2G124‐48(Figure 1‐2)haveseveraltypesoffrontpanel
portconnections,whichinclude:
•RJ45ports (10/100/1000Mbps,10 00BASE‐Tcopperports),24ontheC2G124‐24and48
ontheC2G124‐48
•SFPslotsthatprovideyouwiththeoptionofinstallingSmall
FormPluggable(SFP)
Mini‐GBICsfor1000BASE‐Tcompliantcopperconnectionsor1000BASE‐SX/LX
fiber‐opticconnections
•Rearpanelconnectorsforhigh‐speedconnectionsinastackconfiguration
•RearpanelRedundantPowerSupplyconnectorforaredundantpowersupply
connection.TheswitchconnectstoaC2RPS‐SYSusingaC2RPS‐PSM
Cable.
The10/100/1000 Mbpsfixedfrontpanelportscanoperateineitherhalf‐duplexorfull‐
duplexmode,asdeterminedbyAuto‐Negotiation.
Caution: The C2G124-24 and C2G124-48 are not PoE-compliant devices. Do not
connect a SecureStack C2 PoE Redundant Power System (C2RPS-POE) to the power
connector. Otherwise, damage to the device may result.
Precaución: Los dispositivos C2G124-24 y C2G124-48 no cumplen con el estándar PoE
(power over ethernet). No conecte una fuente de poder redundante (RPS) SecureStack
C2 PoE (C2RPS-POE) al cable de corriente. De lo contrario, el dispositivo puede
dañarse.
Note: The Mini-GBIC ports cannot be active simultaneously with their corresponding
10/100/1000BASE-T ports. For example, if SFP port 24 establishes a link first on the
C2G124-24, the 10/100/1000BASE-T built-in RJ45 port 24 is not available and vice-versa.
