Enterasys SecureStack C2 C2G124-24 User Manual

100BASE-TX Network
2-2 Network Requirements
100BASE-TX Network
Whenconnectinga100BASE‐TXsegmenttooneofthefixedports(1 through24on
C2G124‐24,1through48onC2G124‐48,or1through48onC2H124‐48),useCategory5
UTPcabling.TheswitchattheotherendofthetwistedpairsegmentmustmeetIEEE
802.3‐2002
100BASE‐TXFastEthernetnetworkrequirementsfortheswitchestooperateat
100 Mbps.
1000BASE-FX Network
TheMini‐GBICportsockets(21 through24onC2G124‐24;45through48onC2G124‐48;or
49through52onC2H124‐48)enableyoutovarythetypeof1‐Gbpsportconnection.At
theprintingofthisdocumentthereweresixMini‐GBICsavailablethatsupport
connections,asfollows:

•MGBIC‐LC01fora1000BASE‐SXcompliantLCfiber‐opticmultimodeconnection
•MGBIC‐LC03fora1000BASE‐SXcompliantLCfiber‐opticmultimodeconnection
•MGBIC‐LC09fora1000BASE‐LXcompliantLCfiber‐opticsingle‐modeconnection
•MGBIC‐MT01fora1000BASE‐SXcompliantMT‐RJfiber‐opticsingle‐mode
connection
•MGBIC
‐08fora1000BASE‐ELXcompliantLCfiber‐opticsingle‐modeconnection
Thedeviceattheotherendofthefiberconnectionmustmeet thesameGigabit Ethernet
requirementsfortheconnecteddevicestooperateat1‐Gigabitspeed.
1000BASE-T Network
TheRJ45fixedfrontpanelconnectorsandoptionalSFPMGBIC‐02supportRJ45copper
1000BASE‐Tcompliantconnections.Whenconnectinga1000BASE‐Tsegmenttooneof
theRJ45fixedportsortoanoptionalMGBIC‐02,useCategory5UTPcabling.Thedevice
attheotherendofthetwisted
pairsegmentmustmeetIEEE802.3‐20021000BASE‐T
GigabitEthernetnetworkrequirementsforthedevicestooperateat1000 Mbps.
Note: When using the fixed ports on the switch for 100 Mbps operation use Category 5
UTP cabling with an impedance between 85 and 111 ohms for 100 Mbps operation.
The fixed switch ports are capable of operating at 10, 100 or 1000 Mbps. This is
accomplished by the switch when Auto-Negotiation is enabled. This enables the switch to
automatically sense the transmission speed of the other device and adjust for the speed
accordingly.
