Chapter 1 – Description of the EO-70 device
Front Panel
1.
Display screen
3. EO device h
ousing unit
2.
SMD module
4. Circuit Port
5.
Keyboard
Rear Panel
1. Air inlet / outlet filters cover
5
.
USB
-
1 port
2. DC Power connector
6
. SpO
2
connector
3.
Power button
7
. Remote Control connecto
r
4.
USB
-
2 port
(Maintenance
only)
1
2
3
4
5
2
1
3
4
5
6
7
