Chapter 6 - Device information
Timing Operation
r an intermittent use (non
continuous). The device has to
be in stand-by for a duration equal to the preceding usage time (typical use of 1 min 30 sec
should be followed by a minimum stand-by period of 1 min 30 sec). For clinical reasons, it is
not recommended to exceed 5 minutes of continuous usage.
IPPB mode can be used continuously, within the limits of clinical indications.
Physical Specifications
SMD Module Specifications
Functional Specifications
The EO-70 can be used in the following treatment modes:
INEX: Insufflation - Exsufflation
IPPB: Intermittent Positive Pressure Breathing
INEX
Auto operation
The Auto Mode delivers the therapy accordingly to the settings of: Inhalation Pressure, Exhalation
Pressure, Inhalation Time, Exhalation Time, Pause Time, PEEP and Rise Time. The therapy delivered
will follow the sequence below for the Number of Cycles set or until the user stops the therapy:
PEEP (if set) during the Pause Time.
Inhalation Pressure during the Inhalation Time.
Exhalation Pressure during the Exhalation Time.
The therapy will end following the setting «Treatment end» (Inhalation or exhalation). The time that
the device uses to reach the Inspiratory Pressure depends on the setting of the Rise Time.
In Auto Mode, it is possible to set a Trigger that allows the patient to start the cycle during the pause
period.
Manual operation
The operator will determine the inspiration and exhalation time by switching the touch pad to the left
(triggers an inspiration) and to the right (triggers an exhalation). When the touch pad is released, the
device starts a pause phase and controls PEEP.
