Printing on Continuous Paper
2-19
R4C4620
Rev. C
A5 size CONT.FM
6/14/00 Pass 3
R
Proof Sign-off:
SEI Y.Ohkawara T.Takahashi
T.Takahashi
SEI M.Kauppi K.Blair
9. Fit three holes on each side of the paper over the tractor pins
on both sprockets. Then close the sprocket covers.
10. Slide the right sprocket to remove any slack in the paper, then
lock it in place by pushing the sprocket lock down.
11. If you use the front slot, attach the front cover with the
continuous paper positioned as shown below. Then close it.
12. If you use the rear slot, replace the paper guide and make sure
the edge guides are together in the middle of the paper guide
and lift the center section of the paper guide up and lay it flat.
13. Turn on the printer.
To Next Page
