8.7 Oscillation Characteristics
Oscillation characteristics change depending on conditions (board pattern, components used, etc.). Use the
following characteristics as reference values. In particular, when a ceramic or crystal oscillator is used, use the
oscillator manufacturer recommended values for constants such as capacitance and resistance.
OSC1 crystal oscillation
(Unless otherwise specified: crystal=Q11C02RX
#1
32.768kHz, Rf1=20MΩ, CG1=CD1=15pF
#2
)
Item Symbol Condition Min. Typ. Max. Unit ∗
Operating temperature Ta VDD=2.7V to 3.6V -40 85 °C
VDD=1.9V to 2.2V -40 85 °C
VDD=1.8V to 2.2V 0 70 °C
#1 Q11C02RX: Crystal resonator made by Seiko Epson
#2 "C
G1=CD1=15pF" includes board capacitance.
(Unless otherwise specified: V
DD=3.3V, VSS=0V, crystal=Q11C02RX
#1
32.768kHz,
Rf
1=20MΩ, CG1=CD1=15pF
#2
, Ta=25°C)
Item Symbol Condition Min. Typ. Max. Unit ∗
Oscillation start time tSTA1 3s
External gate/drain capacitance CG1, CD1 CG1=CD1,
including board capacitance
525pF
Frequency/IC deviation ∆f/∆IC -10 10 ppm
Frequency/power voltage deviation ∆f/∆V-1010 ppm/V
Frequency adjustment range ∆f/∆CG CG1=CD1= 5 to 25pF 50 ppm
#1 Q11C02RX: Crystal resonator made by Seiko Epson
#2 "C
G1=CD1=15pF" includes board capacitance.
(Unless otherwise specified: V
DD=2.0V, VSS=0V, crystal=Q11C02RX
#1
32.768kHz,
Rf
1=20MΩ, CG1=CD1=15pF
#2
, Ta=25°C)
Item Symbol Condition Min. Typ. Max. Unit ∗
Oscillation start time tSTA1 20 s
External gate/drain capacitance CG1, CD1 CG1=CD1,
including board capacitance
525pF
Frequency/IC deviation ∆f/∆IC -10 10 ppm
Frequency/power voltage deviation ∆f/∆V-1010 ppm/V
Frequency adjustment range ∆f/∆CG CG1=CD1= 5 to 25pF 50 ppm
#1 Q11C02RX: Crystal resonator made by Seiko Epson
#2 "C
G1=CD1=15pF" includes board capacitance.
OSC3 crystal oscillation
Note:A "crystal resonator that uses a fundamental" should be used for the OSC3 crystal oscillation
circuit.
(Unless otherwise specified: VSS=0V, crystal=Q22MA306
#1
33.8688MHz,
Rf
2=1MΩ, CG1=CD1=15pF
#2
, Ta=25°C)
Item Symbol Condition Min. Typ. Max. Unit ∗
Oscillation start time tSTA3 VDD=3.3V 10 ms
VDD=2.0V 25 ms
#1 Q22MA306: Crystal resonator made by Seiko Epson
#2 "C
G1=CD1=15pF" includes board capacitance.
