Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 User Manual

10 PAD LAYOUT
S1C33L03 PRODUCT PART EPSON A-111
A-1
A-10
10.2 Pad Coordinate
(Unit: µm)
No. Pad name X Y No. Pad name X Y
1P22/TM0 -2310.0 -2549.5 51 #RD 2843.5 -1210.0
2N.C. -2200.0 -2549.5 52 VSS 2843.5 -1100.0
3P23/TM1 -2090.0 -2549.5 53 D15 2843.5 -990.0
4N.C. -1980.0 -2549.5 54 D14 2843.5 -880.0
5VSS -1870.0 -2549.5 55 D13 2843.5 -770.0
6N.C. -1760.0 -2549.5 56 D12 2843.5 -660.0
7P24/TM2/#SRDY2 -1650.0 -2549.5 57 D11 2843.5 -550.0
8N.C. -1540.0 -2549.5 58 VDD 2843.5 -440.0
9P25/TM3/#SCLK2 -1430.0 -2549.5 59 D10 2843.5 -330.0
10 P26/TM4/SOUT2 -1320.0 -2549.5 60 D9 2843.5 -220.0
11 P27/TM5/SIN2 -1210.0 -2549.5 61 D8 2843.5 -110.0
12 VDD -1100.0 -2549.5 62 D7 2843.5 0.0
13 P07/#SRDY1/#DMAEND3 -990.0 -2549.5 63 D6 2843.5 110.0
14 P06/#SCLK1/#DMAACK3 -880.0 -2549.5 64 D5 2843.5 220.0
15 P05/SOUT1/#DMAEND2 -770.0 -2549.5 65 D4 2843.5 330.0
16 P04/SIN1/#DMAACK2 -660.0 -2549.5 66 VDDE 2843.5 440.0
17 FPDAT7 -550.0 -2549.5 67 D3 2843.5 550.0
18 FPDAT6 -440.0 -2549.5 68 D2 2843.5 660.0
19 FPDAT5 -330.0 -2549.5 69 D1 2843.5 770.0
20 FPDAT4 -220.0 -2549.5 70 D0 2843.5 880.0
21 FPDAT3/GPO6 -110.0 -2549.5 71 #CE8/#RAS1/#CE14/#RAS3/#SDCE1 2843.5 990.0
22 FPDAT2/GPO5 0.0 -2549.5 72 #CE7/#RAS0/#CE13/#RAS2/#SDCE0 2843.5 1100.0
23 FPDAT1/GPO4 110.0 -2549.5 73 VSS 2843.5 1210.0
24 FPDAT0/GPO3 220.0 -2549.5 74 OSC2 2843.5 1320.0
25 VDDE 330.0 -2549.5 75 OSC1 2843.5 1430.0
26 DRDY(MOD/FPSHIFT2) 440.0 -2549.5 76 #RESET 2843.5 1540.0
27 FPFRAME 550.0 -2549.5 77 P35/#BUSACK/GPIO1 2843.5 1650.0
28 FPLINE 660.0 -2549.5 78 N.C. 2843.5 1760.0
29 FPSHIFT 770.0 -2549.5 79 P34/#BUSREQ/#CE6/GPIO0 2843.5 1870.0
30 N.C. 880.0 -2549.5 80 P33/#DMAACK1/SIN3/SDA10 2843.5 1980.0
31 LCDPWR 990.0 -2549.5 81 P32/#DMAACK0/#SRDY3/HDQM 2310.0 2549.5
32 N.C. 1100.0 -2549.5 82 N.C. 2200.0 2549.5
33 VSS 1210.0 -2549.5 83 P31/#BUSGET/#GARD/GPIO2 2090.0 2549.5
34 K67/AD7 1320.0 -2549.5 84 N.C. 1980.0 2549.5
35 K66/AD6 1430.0 -2549.5 85 P30/#WAIT/#CE4&5 1870.0 2549.5
36 K65/AD5 1540.0 -2549.5 86 N.C. 1760.0 2549.5
37 K64/AD4 1650.0 -2549.5 87 #LCAS/#SDRAS 1650.0 2549.5
38 K63/AD3 1760.0 -2549.5 88 N.C. 1540.0 2549.5
39 K62/AD2 1870.0 -2549.5 89 #HCAS/#SDCAS 1430.0 2549.5
40 N.C. 1980.0 -2549.5 90 VDD 1320.0 2549.5
41 K61/AD1 2090.0 -2549.5 91 P21/#DWE/#GAAS/#SDWE 1210.0 2549.5
42 K60/AD0 2200.0 -2549.5 92 P20/#DRD/SDCKE 1100.0 2549.5
43 AVDDE 2310.0 -2549.5 93 BCLK/SDCLK 990.0 2549.5
44 K54/#DMAREQ3 2843.5 -1980.0 94 VSS 880.0 2549.5
45 K53/#DMAREQ2 2843.5 -1870.0 95 P16/EXCL5/#DMAEND1/SOUT3 770.0 2549.5
46 K52/#ADTRG 2843.5 -1760.0 96 P15/EXCL4/#DMAEND0/#SCLK3/LDQM 660.0 2549.5
47 K51/#DMAREQ1 2843.5 -1650.0 97 A0/#BSL 550.0 2549.5
48 K50/#DMAREQ0 2843.5 -1540.0 98 A1/SDA0 440.0 2549.5
49 #WRH/#BSH 2843.5 -1430.0 99 A2/SDA1 330.0 2549.5
50 #WRL/#WR/#WE 2843.5 -1320.0 100 A3/SDA2 220.0 2549.5
