Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 User Manual

10 PAD LAYOUT
A-112 EPSON S1C33L03 PRODUCT PART
No. Pad name X Y No. Pad name X Y
101 A4/SDA3 110.0 2549.5 131 VSS -2843.5 1210.0
102 A5/SDA4 0.0 2549.5 132 DSIO -2843.5 1100.0
103 VDDE -110.0 2549.5 133 P14/FOSC1/DCLK -2843.5 990.0
104 A6/SDA5 -220.0 2549.5 134 P13/EXCL3/T8UF3/DPCO -2843.5 880.0
105 A7/SDA6 -330.0 2549.5 135 P12/EXCL2/T8UF2/DST2 -2843.5 770.0
106 A8/SDA7 -440.0 2549.5 136 P11/EXCL1/T8UF1/DST1 -2843.5 660.0
107 A9/SDA8 -550.0 2549.5 137 P10/EXCL0/T8UF0/DST0 -2843.5 550.0
108 A10/SDA9 -660.0 2549.5 138 EA10MD1 -2843.5 440.0
109 A11 -770.0 2549.5 139 EA10MD0 -2843.5 330.0
110 VSS -880.0 2549.5 140 ICEMD -2843.5 220.0
111 A12/SDA11 -990.0 2549.5 141 #EMEMRD -2843.5 110.0
112 A13/SDA12 -1100.0 2549.5 142 VDD -2843.5 0.0
113 A14/SDBA0 -1210.0 2549.5 143 OSC4 -2843.5 -110.0
114 A15/SDBA1 -1320.0 2549.5 144 OSC3 -2843.5 -220.0
115 A16 -1430.0 2549.5 145 #NMI -2843.5 -330.0
116 A17 -1540.0 2549.5 146 #CE9/#CE17/#CE17&18 -2843.5 -440.0
117 VSS -1650.0 2549.5 147 VDDE -2843.5 -550.0
118 N.C. -1760.0 2549.5 148 #CE5/#CE15/#CE15&16 -2843.5 -660.0
119 A18 -1870.0 2549.5 149 N.C. -2843.5 -770.0
120 N.C. -1980.0 2549.5 150 #CE3 -2843.5 -880.0
121 A19 -2090.0 2549.5 151 VSS -2843.5 -990.0
122 N.C. -2200.0 2549.5 152 #CE10EX/#CE9&10EX -2843.5 -1100.0
123 A20 -2310.0 2549.5 153 #CE6/#CE7&8 -2843.5 -1210.0
124 A21 -2843.5 1980.0 154 #CE4/#CE11/#CE11&12 -2843.5 -1320.0
125 A22 -2843.5 1870.0 155 #X2SPD -2843.5 -1430.0
126 A23 -2843.5 1760.0 156 P03/#SRDY0 -2843.5 -1540.0
127 PLLS1 -2843.5 1650.0 157 P02/#SCLK0 -2843.5 -1650.0
128 PLLS0 -2843.5 1540.0 158 N.C. -2843.5 -1760.0
129 VSS -2843.5 1430.0 159 P01/SOUT0 -2843.5 -1870.0
130 PLLC -2843.5 1320.0 160 P00/SIN0 -2843.5 -1980.0
