Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 User Manual

APPENDIX B PIN CHARACTERISTICS
A-128 EPSON S1C33L03 PRODUCT PART
Appendix B Pin Characteristics
CharacteristicPin
No.
Signal name
I/O cell
name
Input Output
Pull-
up/down
Power
supply
Remarks
1P22/TM0 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
2P23/TM1 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
3VSS VSS
4P24/TM2/#SRDY2 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
5P25/TM3/#SCLK2 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
6P26/TM4/SOUT2 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
7P27/TM5/SIN2 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
8VDD LVDD
9P07/#SRDY1/#DMAEND3 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
10 P06/#SCLK1/#DMAACK3 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
11 P05/SOUT1/#DMAEND2 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
12 P04/SIN1/#DMAACK2 XHBH1T CMOS/LVTTL SCHMITT Type1 VDDE
13 FPDAT7 XHBC3BT CMOS/LVTTL Type3 VDDE
14 FPDAT6 XHBC3BT CMOS/LVTTL Type3 VDDE
15 FPDAT5 XHBC3BT CMOS/LVTTL Type3 VDDE
16 FPDAT4 XHBC3BT CMOS/LVTTL Type3 VDDE
17 FPDAT3/GPO6 XHBC3BT CMOS/LVTTL Type3 VDDE
18 FPDAT2/GPO5 XHBC3BT CMOS/LVTTL Type3 VDDE
19 FPDAT1/GPO4 XHBC3BT CMOS/LVTTL Type3 VDDE
20 FPDAT0/GPO3 XHBC3BT CMOS/LVTTL Type3 VDDE
21 VDDE HVDD
22 DRDY(MOD/FPSHIFT2) XHBC3BT CMOS/LVTTL Type3 VDDE
23 FPFRAME XHBC3BT CMOS/LVTTL Type3 VDDE
24 FPLINE XHBC3BT CMOS/LVTTL Type3 VDDE
25 FPSHIFT XHBC3BT CMOS/LVTTL Type3 VDDE
26 LCDPWR XHTB1T Type1 VDDE
27 VSS VSS
28 K67/AD7 XHIBCLINW CMOS/LVTTL AVDDE note 1
29 K66/AD6 XHIBCLINW CMOS/LVTTL AVDDE note 1
30 K65/AD5 XHIBCLINW CMOS/LVTTL AVDDE note 1
31 K64/AD4 XHIBCLINW CMOS/LVTTL AVDDE note 1
32 K63/AD3 XHIBCLINW CMOS/LVTTL AVDDE note 1
33 K62/AD2 XHIBCLINW CMOS/LVTTL AVDDE note 1
34 K61/AD1 XHIBCLINW CMOS/LVTTL AVDDE note 1
35 K60/AD0 XHIBCLINW CMOS/LVTTL AVDDE note 1
36 AVDDE HVDD
37 K54/#DMAREQ3 XHIBHP2 CMOS/LVTTL SCHMITT Pull-up VDDE
38 K53/#DMAREQ2 XHIBHP2 CMOS/LVTTL SCHMITT Pull-up VDDE
39 K52/#ADTRG XHIBHP2 CMOS/LVTTL SCHMITT Pull-up VDDE
40 K51/#DMAREQ1 XHIBHP2 CMOS/LVTTL SCHMITT Pull-up VDDE
41 K50/#DMAREQ0 XHIBHP2 CMOS/LVTTL SCHMITT Pull-up VDDE
42 #WRH/#BSH XHBC1T note 3 Type1 VDDE
43 #WRL/#WR/#WE XHBC1T note 3 Type1 VDDE
44 #RD XHBC1T note 3 Type1 VDDE
45 VSS VSS
46 D15 XHBC1T CMOS/LVTTL Type1 VDDE
47 D14 XHBC1T CMOS/LVTTL Type1 VDDE
48 D13 XHBC1T CMOS/LVTTL Type1 VDDE
49 D12 XHBC1T CMOS/LVTTL Type1 VDDE
50 D11 XHBC1T CMOS/LVTTL Type1 VDDE
