Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 User Manual

1 OUTLINE
S1C33L03 PRODUCT PART EPSON A-5
A-1
1.3.2 Pin Functions
Table 1.3.1 List of Pins for Power Supply System
Pin name Pin No. I/O Pull-up Function
VDD 8,51,78,127 – – Power supply (+) for the internal logic
VSS 3,27,45,66,
82,98,105,
114,116,136
––Power supply (-); GND
VDDE 21,59,91,132 – – Power supply (+) for the I/O block
AVDDE 36 – – Analog system power supply (+); AVDDE = VDDE
Table 1.3.2 List of Pins for External Bus Interface Signals
Pin name Pin No. I/O Pull-up Function
A0
#BSL
85 O – A0: Address bus (A0) when SBUSST(D3/0x4812E) = "0" (default)
#BSL: Bus strobe (low byte) signal when SBUSST(D3/0x4812E) = "1"
A[10:1]
SDA[9:0]
85–90,92–96 O
–
A[10:1]: Address bus (A1–A10)
SDA[9:0]: SDRAM address bus (SDA0–SDA9)
A11 97 O – Address bus (A11)
A[13:12]
SDA[12:11]
99,100 O – A[13:12]: Address bus (A12–A13)
SDA[12:11]: SDRAM address bus (SDA11–SDA12)
A[15:14]
SDBA[1:0]
101,102 O – A[15:14]: Address bus (A14–A15)
SDBA[1:0]: SDRAM bank select (SDBA0–SDBA1)
A[23:16] 103,104,
106–111
O–Address bus (A16–A23)
D[15:0] 46–50,52–58,
60–63
I/O – Data bus (D0–D15)
#CE10EX
#CE9&10EX
137 O – Area 10 chip enable for external memory
* When CEFUNC[1:0] = "1x", this pin outputs #CE9+#CE10EX signal.
#CE9
#CE17
#CE17&18
131 O – #CE9: Area 9 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "00" (default)
#CE17: Area 17 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "01"
* When CEFUNC[1:0] = "1x", this pin outputs #CE17+#CE18 signal.
#CE8
#RAS1
#CE14
#RAS3
#SDCE1
64 O – #CE8: Area 8 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "00",
A8DRA(D8/0x48128) = "0" and SDRPC1(D2/0x39FFC0) = "0" (default)
#RAS1: Area 8 DRAM row strobe when CEFUNC[1:0](D[A:9]/0x48130) = "00",
A8DRA(D8/0x48128) = "1" and SDRPC1(D2/0x39FFC0) = "0"
#CE14: Area 14 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "01" or "1x",
A14DRA(D8/0x48122) = "0" and SDRPC1(D2/0x39FFC0) = "0"
#RAS3: Area 14 DRAM row strobe when CEFUNC[1:0](D[A:9]/0x48130) = "01" or
"1x", A14DRA(D8/0x48122) = "1" and SDRPC1(D2/0x39FFC0) = "0"
#SDCE1: SDRAM chip enable 1 when SDRPC1(D2/0x39FFC0) = "1" and
SDRENA(D7/0x39FFC1) = "1"
#CE7
#RAS0
#CE13
#RAS2
#SDCE0
65 O – #CE7: Area 7 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "00",
A7DRA(D7/0x48128) = "0" and SDRPC0(D3/0x39FFC0) = "0" (default)
#RAS0: Area 7 DRAM row strobe when CEFUNC[1:0](D[A:9]/0x48130) = "00",
A7DRA(D7/0x48128) = "1" and SDRPC0(D3/0x39FFC0) = "0"
#CE13: Area 13 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "01" or "1x",
A13DRA(D7/0x48122) = "0" and SDRPC0(D3/0x39FFC0) = "0"
#RAS2: Area 13 DRAM row strobe when CEFUNC[1:0](D[A:9]/0x48130) = "01" or
"1x", A13DRA(D7/0x48122) = "1" and SDRPC0(D3/0x39FFC0) = "0"
#SDCE0: SDRAM chip enable 0 when SDRPC0(D3/0x39FFC0) = "1" and
SDRENA(D7/0x39FFC1) = "1"
#CE6
#CE7&8
138 O – Area 6 chip enable
* When CEFUNC[1:0] = "1x", this pin outputs #CE7+#CE8 signal.
#CE5
#CE15
#CE15&16
133 O – #CE5: Area 5 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "00" (default)
#CE15: Area 15 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "01"
* When CEFUNC[1:0] = "1x", this pin outputs #CE15+#CE16 signal.
#CE4
#CE11
#CE11&12
139 O – #CE4: Area 4 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "00" (default)
#CE11: Area 11 chip enable when CEFUNC[1:0](D[A:9]/0x48130) = "01"
* When CEFUNC[1:0] = "1x", this pin outputs #CE11+#CE12 signal.
#CE3 135 O – Area 3 chip enable
#RD 44 O – Read signal
#EMEMRD 126 O – Read signal for internal ROM emulation memory
