8 ELECTRICAL CHARACTERISTICS
A-76 EPSON S1C33L03 PRODUCT PART
8.5 A/D Converter Characteristics
1) 3.3 V/5.0 V dual power source
(Unless otherwise specified: VDDE=AVDDE=4.5V to 5.5V, VDD=2.7V to 3.6V, VSS=0V, Ta=-40°C to +85°C, ST[1:0]=11)
Item Symbol Condition Min. Typ. Max. Unit ∗
Resolution – – 10 – bit
Conversion time – 5––µs1
Zero scale error EZS 024LSB
Full scale error EFS -2 – 2 LSB
Integral linearity error EL -3 – 3 LSB
Differential linearity error ED -3 – 3 LSB
Permissible signal source impedance – – – 5 kΩ
Analog input capacitance – – – 45 pF
∗ note 1) Indicates the minimum value when A/D clock = 4MHz (maximum clock frequency in 5V system).
Indicates the maximum value when A/D clock = 32kHz (minimum clock frequency in 5V system).
2) 3.3 V single power source
(Unless otherwise specified: VDDE=AVDDE=VDD=2.7V to 3.6V, VSS=0V, Ta=-40°C to +85°C, ST[1:0]=11)
Item Symbol Condition Min. Typ. Max. Unit ∗
Resolution – – 10 – bit
Conversion time – 10 – 625 µs 1
Zero scale error EZS 024LSB
Full scale error EFS -2 – 2 LSB
Integral linearity error EL -3 – 3 LSB
Differential linearity error ED -3 – 3 LSB
Permissible signal source impedance – – – 5 kΩ
Analog input capacitance – – – 45 pF
∗ note 1) Indicates the minimum value when A/D clock = 2MHz (maximum clock frequency in 3V system).
Indicates the maximum value when A/D clock = 32kHz (minimum clock frequency in 3V system).
Note:•Be sure to use as VDDE = AVDDE.
•The A/D converter cannot be used when the S1C33L03 is used with a 2V power source.
A/D conversion error
V[000]h = Ideal voltage at zero-scale point (=0.5LSB)
V'[000]h = Actual voltage at zero-scale point
V[3FF]h = Ideal voltage at full-scale point (=1022.5LSB)
V'[3FF]h = Actual voltage at full-scale point
1LSB =
1LSB' =
AV DDE - V SS
2
10
- 1
V'[3FF]h - V'[000]h
2
10
- 2
