A-8 EPSON S1C33L03 PRODUCT PART
Table 1.3.4 List of Pins for Internal Peripheral Circuits
Pin name Pin No. I/O Pull-up Function
K50
#DMAREQ0
41 I Pull-up K50: Input port when CFK50(D0/0x402C0) = "0" (default)
#DMAREQ0: HSDMA Ch. 0 request input when CFK50(D0/0x402C0) = "1"
K51
#DMAREQ1
40 I Pull-up K51: Input port when CFK51(D1/0x402C0) = "0" (default)
#DMAREQ1: HSDMA Ch. 1 request input when CFK51(D1/0x402C0) = "1"
K52
#ADTRG
39 I Pull-up K52: Input port when CFK52(D2/0x402C0) = "0" (default)
#ADTRG: A/D converter trigger input when CFK52(D2/0x402C0) = "1"
K53
#DMAREQ2
38 I Pull-up K53: Input port when CFK53(D3/0x402C0) = "0" (default)
#DMAREQ2: HSDMA Ch. 2 request input when CFK53(D3/0x402C0) = "1"
K54
#DMAREQ3
37 I Pull-up K54: Input port when CFK54(D4/0x402C0) = "0" (default)
#DMAREQ3: HSDMA Ch. 3 request input when CFK54(D4/0x402C0) = "1"
K60
AD0
35 I – K60: Input port when CFK60(D0/0x402C3) = "0" (default)
AD0: A/D converter Ch. 0 input when CFK60(D0/0x402C3) = "1"
K61
AD1
34 I – K61: Input port when CFK61(D1/0x402C3) = "0" (default)
AD1: A/D converter Ch. 1 input when CFK61(D1/0x402C3) = "1"
K62
AD2
33 I – K62: Input port when CFK62(D2/0x402C3) = "0" (default)
AD2: A/D converter Ch. 2 input when CFK62(D2/0x402C3) = "1"
K63
AD3
32 I – K63: Input port when CFK63(D3/0x402C3) = "0" (default)
AD3: A/D converter Ch. 3 input when CFK63(D3/0x402C3) = "1"
K64
AD4
31 I – K64: Input port when CFK64(D4/0x402C3) = "0" (default)
AD4: A/D converter Ch. 4 input when CFK64(D4/0x402C3) = "1"
K65
AD5
30 I – K65: Input port when CFK65(D5/0x402C3) = "0" (default)
AD5: A/D converter Ch. 5 input when CFK65(D5/0x402C3) = "1"
K66
AD6
29 I – K66: Input port when CFK66(D6/0x402C3) = "0" (default)
AD6: A/D converter Ch. 6 input when CFK66(D6/0x402C3) = "1"
K67
AD7
28 I – K67: Input port when CFK67(D7/0x402C3) = "0" (default)
AD7: A/D converter Ch. 7 input when CFK67(D7/0x402C3) = "1"
P00
SIN0
144 I/O – P00: I/O port when CFP00(D0/0x402D0) = "0" (default)
SIN0:Serial I/F Ch. 0 data input when CFP00(D0/0x402D0) = "1"
P01
SOUT0
143 I/O – P01: I/O port when CFP01(D1/0x402D0) = "0" (default)
SOUT0: Serial I/F Ch. 0 data output when CFP01(D1/0x402D0) = "1"
P02
#SCLK0
142 I/O – P02: I/O port when CFP02(D2/0x402D0) = "0" (default)
#SCLK0: Serial I/F Ch. 0 clock input/output when CFP02(D2/0x402D0) = "1"
P03
#SRDY0
141 I/O – P03: I/O port when CFP03(D3/0x402D0) = "0" (default)
#SRDY0: Serial I/F Ch. 0 ready signal input/output when CFP03(D3/0x402D0) = "1"
P04
SIN1
#DMAACK2
12 I/O – P04: I/O port when CFP04(D4/0x402D0) = "0" and CFEX4(D4/0x402DF) = "0"
(default)
SIN1:Serial I/F Ch. 1 data input when CFP04(D4/0x402D0) = "1" and
CFEX4(D4/0x402DF) = "0"
#DMAACK2: HSDMA Ch. 2 acknowledge output when CFEX4(D4/0x402DF) = "1"
P05
SOUT1
#DMAEND2
11 I/O – P05: I/O port when CFP05(D5/0x402D0) = "0" and CFEX5(D5/0x402DF) = "0"
(default)
SOUT1: Serial I/F Ch. 1 data output when CFP05(D5/0x402D0) = "1" and
CFEX5(D5/0x402DF) = "0"
#DMAEND2: HSDMA Ch. 2 end-of-transfer signal output when
CFEX5(D5/0x402DF) = "1"
P06
#SCLK1
#DMAACK3
10 I/O – P06: I/O port when CFP06(D6/0x402D0) = "0" and CFEX6(D6/0x402DF) = "0"
(default)
#SCLK1: Serial I/F Ch. 1 clock input/output when CFP06(D6/0x402D0) = "1" and
CFEX6(D6/0x402DF) = "0"
#DMAACK3: HSDMA Ch. 3 acknowledge output when CFEX6(D6/0x402DF) = "1"
P07
#SRDY1
#DMAEND3
9 I/O – P07: I/O port when CFP07(D7/0x402D0) = "0" and CFEX7(D7/0x402DF) = "0"
(default)
#SRDY1: Serial I/F Ch. 1 ready signal output when CFP07(D7/0x402D0) = "1" and
CFEX5(D5/0x402DF) = "0"
#DMAEND3: HSDMA Ch. 3 end-of-transfer signal output when
CFEX7(D7/0x402DF) = "1"
P10
EXCL0
T8UF0
DST0
122 I/O – P10: I/O port when CFP10(D0/0x402D4) = "0" and CFEX1(D1/0x402DF) = "0"
EXCL0: 16-bit timer 0 event counter input when CFP10(D0/0x402D4) = "1",
IOC10(D0/0x402D6) = "0" and CFEX1(D1/0x402DF) = "0"
T8UF0: 8-bit timer 0 output when CFP10(D0/0x402D4) = "1", IOC10(D0/0x402D6)
= "1" and CFEX1(D1/0x402DF) = "0"
DST0:DST0 signal output when CFEX1(D1/0x402DF) = "1" (default)
