Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 User Manual

VI SDRAM CONTROLLER BLOCK: SDRAM INTERFACE
B-VI-2-4 EPSON S1C33L03 FUNCTION PART
Notes:•Because the SDRAM address bus pins differ in bit numbers from ordinary external address pin
names, care must be taken when connecting an SDRAM to the S1C33. (SDRAM address
SDA0 is output from the A1 pin, and SDA12 is output from the A13 pin.) Furthermore, the
SDA10 signal with a special function is assigned to the P33 pin, and not to the address bus
A11.
•If designated pins (e.g., CKE and DQM[1:0] pins) must be driven high before the SDRAM can
be powered on, add external pull-up resistors or use a separate power supply for the SDRAM.
•To prevent a malfunction, take measures against noise when designing the board patterns for
the SDRAM.
Table 2.2 lists several examples of SDRAM chip configurations. All of these examples use only one area of the
S1C33. If your design uses two areas, the same type of memory needs to be used in each area because SDRAM-
related settings are common to both areas.
Table 2.2 Chip Configuration Example (when one area only is used)
SDRAM
Number of
devices
Memory size
256M (4M x 16 bits x 4 banks) 1 32M bytes
256M (8M x 8 bits x 4 banks) 1 32M bytes
128M (2M x 16 bits x 4 banks) 1 16M bytes
128M (4M x 8 bits x 4 banks) 1 16M bytes
232M bytes
64M (1M x 16 bits x 4 banks) 1 8M bytes
64M (2M x 8 bits x 4 banks) 1 8M bytes
216M bytes
16M (512 x 16 bits x 2 banks) 1 2M bytes
16M (1M x 8 bits x 2 banks) 1 2M bytes
24M bytes
