Epson EB-770F User Manual

163
6. Adjust the brightness and tone of the areas that do not overlap to match the areas that overlap using
the displayed adjustment sliders. Then press the Esc button.
7. Repeat the previous two steps as needed until all areas match.
8. If the tone of some areas do not match, you can adjust them using the Area Correction setting.
Continue with the next step. Otherwise, press the Menu button to exit.
9. Press the Esc button to return to the Black Level screen.
10. Select the Area Correction setting and press Enter.
11. Select the Start Adjustments setting and press Enter.
You see a screen with boundary lines indicating areas that are overlapping. The boundary lines are
based on the Top Edge, Bottom Edge, Right Edge, and Left Edge settings you selected for the
Edge Blending setting.
12. Use the arrow buttons to select a boundary line of the area you want to adjust and press Enter.
The selected line is displayed in orange.
13. Use the arrow buttons to adjust the boundary line position and press Enter.

Epson EB-770F Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	57 - 150 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Focus	Manual
Throw ratio	0.25
Zoom capability	Yes
Fixed focal length	3.7 mm
Light source type	Laser
Service life of light source	- h
Product type	Ultra short throw projector
Product color	White
Market positioning	Education
Cable lock slot type	Kensington
Audio (L/R) in	-
Composite video in	0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
RMS rated power	16 W
Number of built-in speakers	1
Analog signal format system	Not supported
Power source	AC
Power consumption (standby)	2 W
Power consumption (typical)	263 W
Display diagonal	0.62 \
Noise level	37 dB
Noise level (economic mode)	27 dB

Weight and Dimensions

Depth	395 mm
Width	357 mm
Height	165 mm
Weight	5900 g
