Epson EB-E10 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 12 Revision A
1.2 Specifications
 EB-E01/X06/W06/E10/X51/W51/W52
Model
EB-E01 EB-X06 EB-W06 EB-E10 EB-X51 EB-W51 EB-W52
Item
Specific
ation
of main
part
LCD
Size
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.59 inch
(C2fine)
Pixel number
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
1,024,000 pixels
(1280 x 800) x 3
Native resolution XGA XGA WXGA XGA XGA WXGA WXGA
Aspect ratio 4:3 4:3 16:10 4:3 4:3 16:10 16:10
Projection Lens
Focus Type Manual
Zoom
Type Digital Manual Manual Digital Manual Manual Manual
Ratio 1-1.35 1-1.2 1-1.2 1-1.35 1-1.2 1-1.2 1-1.2
Lamp
Type UHE
Power consumption 210W
Life
Normal 6,000 hours
Eco 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,300lm 3,600lm 3,700lm 3,600lm 3,800lm 4,000lm 4,000lm
Eco mode
Color mode: Dynamic,
Zoom: Wide
2,200lm 2,400lm 2,400lm 2,200lm 2,500lm 2,600lm 2,600lm
Sound output Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding)
RCA — 1 (Yellow) 1 (Yellow) — 1 (Yellow) 1 (Yellow) 1 (Yellow)
Digital HDMI 1
Video output Analog D-sub 15pin —
Audio
Input
RCA (L/R)—11—111
Stereo mini —
Output Stereo mini —
Mic Input Stereo mini —

Epson EB-E10 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	22 - 350 \
Projection distance (wide)	0.87 - 10.34 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Full HD	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
AC (power) in	Yes
Composite video in	0
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Housing material	Plastic
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
USB display function	2 in 1: Image / Mouse

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	376 mm
Package width	327 mm
Package height	152 mm
Package weight	3716 g
