EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 70 Revision A
3.2 Flowchart
EB-E01/X06/W06/FH06/E10/X51/W51/FH52/E20/X49/W49/972/982W/992F/W52/118_EH-TW740/TW750_PL 119W The general disassembly procedure for
the projector is illustrated in the flowchart below. Unless otherwise specified, all reassembly should becarried out by following the disassembly procedures in
reverse, therefore reassembling procedures are omitted.
3.2.1 Standard operation time
The standard operation time for each operation is provided on the flowchart. Use the time as a guideline for actual operations.
Basis for the standard operation time
A service employee would have sufficient knowledge for the target product’s structure, and be able to disassemble/reassemble the product without any
reference to guide books.
Each operation time is the total time of disassembling/reassembling the target part following the given shortest procedure, and reassembling it.
The part names in this chapter are written as abbreviations. See 3.9 Part Names List (p166) for the names of the after service parts in the SPI
(Service Parts Information).
The parts in colored boxes are target parts in their category. They are explained in details in the corresponding sections so as to reach the
parts in the shortest way.
The parts in gray boxes are those which are required to be removed to reach the target parts.
To Next Page
